Interface® Compressed-Fiber Gaskets.
Interface Performance Materials, Inc. is the former Armstrong World Industries fiber-gasket business. The product line covers compressed cellulose, nitrile-bound cellulose, aramid-reinforced, and cylinder-head facing materials, all non-asbestos.
Quick facts about Interface
- Specified across automotive, small engine, compressor, pump, HVAC, chemical processing, and industrial equipment manufacturers. ASTM F-104 designations published on every datasheet.
- Cannon Gasket die-cuts all 36 Interface compounds on demand. Families include TN series (aramid + nitrile), TS series (aramid + SBR, controlled swell), NI cylinder-head facings, NV nitrile cellulose, Pro-Formance, and standard cellulose.
- We stock the full range and cut to customer drawings under ISO 9001 quality systems. PSA backing, pad printing, and kitting available.
- Send a drawing, part number, or a reference to a specific Interface grade. We reply with unit pricing, tooling, and lead time.
Get pricing
Request a quote for Interface gaskets.
The Interface Performance Materials product line
Interface compressed-fiber gaskets are a long-running standard in industries that need a non-asbestos cellulose or aramid-based gasket with a specific binder chemistry. Interface publishes an ASTM F-104 designation on every datasheet so the buyer can cross-reference density, compressibility, recovery, tensile, and fluid-resistance numbers against competing materials.
We cut all 36 grades below. Pick the family by application, then the specific code by service media. If you are cross-referencing a gasket already specified by an OEM or prior supplier, the PDF link on each row pulls the supplier datasheet.
Interface is part of our non-asbestos gasket program. If you are not sure which Interface compound fits your flange or service, start with the gasket material selection guide or send us the drawing and media list.
Standard cellulose, SBR binder
Standard cellulose, SBR binder.
General-purpose, light-duty compressed cellulose gaskets with styrene butadiene rubber binders. Good for low-pressure flanges, irrigation manifolds, and consumer-duty sealing.
| Code | Description | ASTM F-104 | Datasheet |
|---|---|---|---|
| 2331 | 2331 is an environmentally compatible, low density gasket material formulated from recycled gasket materials. | F339177E73M4 | Spec Sheet → |
| CS-301 | CS-301 has a controlled-swell styrene butadiene rubber binder. | F339996E99M9 | Spec Sheet → |
| S-207 | S-207 is a cellulose fiber gasket material with controlled-swell styrene butadiene rubber binder. | F339999E99M9 | Spec Sheet → |
| S-8091 | S-8091 is controlled-swell, latent cure styrene butadiene bound material with reinforced cellulose fiber. | F724900E09M9 | Spec Sheet → |
| SV-360 | SV-360 is a low density cellulose fiber material with styrene butadiene rubber binder. | F339197E93M5 | Spec Sheet → |
Nitrile-bound cellulose (oil, fuel, water)
Nitrile-bound cellulose (oil, fuel, water).
Cellulose fiber bound with nitrile butadiene rubber. Resists petroleum fluids, coolant, and water. The workhorse family for automotive, pump, and compressor gasketing.
| Code | Description | ASTM F-104 | Datasheet |
|---|---|---|---|
| CN-705 | CN-705 is a low-density, nitrile butadiene bound material that is suitable for use with oil, gasoline, and water. | F339199E99M9 | Spec Sheet → |
| N-2085G | N-2085G is a fully cured nitrile butadiene bound material that offers excellent resistance to water, coolant, oil, and fuel. | F723940E43M6 | Spec Sheet → |
| N-8051 | N-8051 is a light-duty material for low internal pressure and low flange pressure applications up to 13.8 MPa (2000 psi). | n/a | Spec Sheet → |
| N-8090 | N-8090 has a latent cure nitrile butadiene rubber binder and reinforced cellulose fiber. | F724900E49M6 | Spec Sheet → |
| N-8092 | N-8092 is used in automotive, small engine, and compressor applications. | F729900E59M9 | Spec Sheet → |
| N-8094 | N-8094 is a low density material that conforms well to irregular flange surfaces and has very good crush resistance at high flange pressures. | F729900E99M9 | Spec Sheet → |
| NI-2085 | NI-2085 has a nitrile butadiene rubber binder for resistance to water, coolant, oil and fuel. | F723940E43M6 | Spec Sheet → |
| NI-2086 | NI-2086 has a fully cured nitrile butadiene rubber binder for improved strength and fluid resistance. | F723940E43M6 | Spec Sheet → |
| NV-512 | NV-512 is a cellulose fiber material with a fully cured nitrile butadiene rubber binder for increased strength and fluid resistance. | F333949E43M7 | Spec Sheet → |
| NV-519 | NV-519 is a cellulose fiber material with thermoset resin and nitrile butadiene rubber binder. | F332949M8 | Spec Sheet → |
| NV-565 | NV-565 is a low density cellulose fiber gasket material with a blend of rubber binders for good oil, fuel, and water resistance. | F339997E93M9 | Spec Sheet → |
| RN-8011 | RN-8011 is a low density cellulose fiber material with high rubber filler content and a nitrile butadiene rubber binder. | F339099E09M9 | Spec Sheet → |
Cylinder head facing material
Cylinder head facing material.
Non-asbestos facing materials engineered for cylinder head, manifold, and exhaust sealing. Paired with solid or perforated metal cores for high-temperature engine applications.
| Code | Description | ASTM F-104 | Datasheet |
|---|---|---|---|
| NI-2095A | NI-2095A is a cylinder head facing material designed to deliver the performance required by worldwide cylinder head applications. | F729150E92M9 | Spec Sheet → |
| NI-2096 | NI-2096 is a cylinder head facing material designed to deliver the performance required by worldwide cylinder head applications. | F729990E52M9 | Spec Sheet → |
| NI-2097A | NI-2097A is a non-asbestos cylinder head facing material with inorganic fillers and fibers encapsulated by nitrile butadiene rubber binder. | F729190E93M9 | Spec Sheet → |
| NI-2098 | NI-2098 is a heavy-duty cylinder head facing material that is used with both solid and perforated metal cores. | F729990E52M2 | Spec Sheet → |
| NI-2900 | NI-2900 is a non-asbestos facing material designed to deliver the performance required by worldwide cylinder head and manifold applications. | F729150E52M9 | Spec Sheet → |
| NI-4002 | NI-4002 is a non-asbestos facing material that, when combined on perforated metal core, is intended for elevated temperature applications such as exhaust systems. | F339997E92M9 | Spec Sheet → |
TN series, aramid + nitrile
TN series, aramid + nitrile.
Heavy-duty aramid-reinforced materials with nitrile binders. Higher tensile, better creep resistance, and broader temperature service than plain cellulose.
| Code | Description | ASTM F-104 | Datasheet |
|---|---|---|---|
| TN-9000 | TN-9000 has a fully cured nitrile butadiene binder with Aramid fiber. | F729900E33M9 | Spec Sheet → |
| TN-9001 | TN-9001 is a heavy-duty latent cure material with nitrile binder. | F729900E49M6 | Spec Sheet → |
| TN-9004 | TN-9004 is a heavy-duty, high density material with fully cured nitrile butadiene rubber binder. | F729100E33M9 | Spec Sheet → |
| TN-9005 | TN-9005 is a heavy-duty material with a latent cure nitrile binder system. | F729900E59M5 | Spec Sheet → |
| TN-9014 | TN-9014 has a fully cured nitrile butadiene rubber binder and a blend of cellulose and Aramid Fibers. | F729900E99M9 | Spec Sheet → |
| TN-9015 | TN-9015 has a latent cure nitrile butadiene rubber binder and has a blend of Aramid and cellulose fibers. | F729900E99M5 | Spec Sheet → |
| TN-9040 | TN-9040 gasket material is a high density product with a fully cured nitrile butadiene rubber binder. | F729900E43M8 | Spec Sheet → |
| TN-9045 | TN-9045 is a heavy-duty material for use in elevated temperature applications. | F729900E93M5 | Spec Sheet → |
TS series, aramid + SBR (controlled-swell)
TS series, aramid + SBR (controlled-swell).
Aramid-reinforced styrene butadiene compounds tuned for controlled swell in water and dilute chemistries. Heavy-duty sealing where the media is water-side rather than oil-side.
| Code | Description | ASTM F-104 | Datasheet |
|---|---|---|---|
| TS-9003 | TS-9003 is a controlled-swell gasket material with a latent cure styrene butadiene rubber binder. | F729900E09M4 | Spec Sheet → |
| TS-9006 | TS-9006 is a heavy-duty, high density gasket material with fully cured styrene butadiene rubber binder. | F729900E09M5 | Spec Sheet → |
| TS-9013 | TS-9013 is a controlled-swell material with latent cure styrene butadiene rubber binder and a blend of Aramid and cellulose fibers. | F729900E09M9 | Spec Sheet → |
| TS-9016 | TS-9016 has a fully cured styrene butadiene rubber binder and a blend of Aramid and cellulose fibers. | F729900E09M9 | Spec Sheet → |
Pro-Formance / MicroPore
Pro-Formance / MicroPore.
Premium nitrile-bound compound with micro-porous structure for maximum sealability on challenging flange surfaces.
| Code | Description | ASTM F-104 | Datasheet |
|---|---|---|---|
| PF-4N | PF-4N has a fully cured nitrile butadiene rubber binder for maximum fluid resistance. | F729000M9 | Spec Sheet → |
Not sure which grade fits?
Interface’s 36-grade catalog is deep because the binder chemistry, fiber content, and cure state all drive performance. The short version of how to narrow down:
- Oil, fuel, or coolant contact? Start in the nitrile-bound family (CN-705, N-8090, NI-2085, NV-565) or step up to the TN series if the flange is also hot.
- Cylinder head or manifold? NI-2095A, NI-2096, NI-2097A, NI-2098, NI-2900, and NI-4002 are purpose-built for cylinder-head facing, often bonded to a steel core.
- Water or dilute chemistry? Use the controlled-swell TS series or the standard SBR-bound grades (2331, CS-301, S-207, SV-360) for lower-duty water service.
- Light-duty or prototype? 2331 or N-8051 cover general-purpose, low-pressure use without the cost of the aramid-reinforced grades.
If you already know the competing supplier part you’re cross-referencing (for example a Garlock, Thermoseal, or Armstrong code), send us the number and we’ll quote the Interface equivalent. Engineering help is on the phone at 909.355.1547.
AI reference
Download the Interface expert skill.
A Claude Skill .md covering all 36 Interface grades, family selection, ASTM F-104 designations, and when to pick which code. Drop it into Claude Desktop, Claude Code, or any agent that supports Anthropic Skills and you get an Interface material expert on demand.
Download Interface Skill .mdFrequently Asked Questions
Common questions about Interface gasket grades.
Are you ISO 9001 certified?
Yes, ISO 9001:2015 certified. Documented quality management covers incoming material verification, in-process inspection, calibrated measurement, final inspection, non-conformance handling, corrective action, and full lot traceability. AS9100-ready for aerospace, with MIL-spec and FDA 21 CFR 177.2600 / USP Class VI grades available on request.
Can you cut custom gasket profiles?
Yes. Custom steel-rule and rotary tooling is built in-house from your drawing or DXF. Complex profiles, multiple through-cuts, tight bolt patterns, and irregular perimeters are all standard work.
Can you supply PSA-backed gaskets?
Yes. Pressure-sensitive adhesive backing is a standard option on most rubber and fiber gasketing, with either permanent or removable liners. Kiss-cut on liner and through-cut both supported on flatbed and rotary presses.
What Interface Performance Materials grades do you stock?
All 36 published grades. Standard cellulose with SBR binder (2331, CS-301, S-207, S-8091, SV-360), nitrile-bound cellulose (CN-705, N-8090, NI-2085, NV-565, PF-4N, RN-8011), cylinder-head facings (NI-2095A, NI-2096, NI-2097A, NI-2098, NI-2900, NI-4002), TN series aramid+nitrile, TS series aramid+SBR, and Pro-Formance.
What tolerances can you hold on gasket dimensions?
Standard die-cut tolerance is ±0.010 to ±0.015 inch on OD and ID, depending on material durometer and thickness. Tighter tolerances are available on select grades and thicknesses. Ask if your drawing specifies something tighter and we will confirm feasibility during the quote.
Which Interface family is right for my application?
Oil/fuel/coolant at moderate temperature: nitrile-bound cellulose (CN-705, N-8090, NI-2085). Cylinder head or manifold: NI-2095A, NI-2096, NI-2097A series. Water or dilute chemistry: TS series or standard SBR-bound (2331, CS-301). Heavy-duty aramid reinforcement: TN series.
Which gasket material is right for my application?
Start with temperature range, fluid contact, and regulatory requirements. Buna-N is the default for oil and fuel. EPDM for weather, water, and steam. Silicone for extreme temperature and FDA grades. Viton for aggressive chemicals. Our gasket material selection guide walks through the decision framework.
How fast do you return a quote?
Most RFQs come back within one business day. Simple profile updates to an existing tool quote same-day. Send a drawing, DXF, or competing part number and our engineering team reviews material, tolerance, and volume before pricing.
What is the minimum order quantity?
Minimums depend on the part and material. We cut prototype and first-article quantities for engineering evaluation, then scale up to production volumes from the same tooling. For high-volume programs we run JIT, VMI, and Kanban replenishment out of Fontana, California.
What should I send with an RFQ?
Ideal: a drawing or DXF, material spec (or compound family), estimated annual volume, and any regulatory callouts (FDA, USP Class VI, AS9100, MIL-spec). If you only have a sample or a part number from a competing supplier, send that and we will reverse-engineer the spec before quoting.
What are typical lead times?
Prototype and first-article parts usually ship in 5-10 business days. Production runs from existing tooling are 2-3 weeks depending on volume and material lead time. Rush and expedite options available on a case-by-case basis.
Need Interface gaskets?
Send a drawing, a part number, or a competing supplier code. We quote pricing, tooling, and lead time inside one business day.
